VCT Heat Exchanger Circuit

2405426
6750190
PET/CT
GE Healthcare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Satisfied safety and regulatory standards
  • Electromagnetic compatibility
  • Functionally tested
  • Easy mounting

Product Overview

The VCT Heat Exchanger Circuit is a component of the Performix PRO VCT Heat Exchanger assembly that is used in the Light Speed 7. x CT scanner. The VCT Power I/F Board provides a central interface for the low voltage components of the Hercules tube and heat exchanger. It routes the power supply voltage to the heat exchanger and oil pump. It contains some solid-state relays that are used for the blown fuse and oil pump cable connection, fan power detection and oil pump on/off control. It provides an interface and circuitry to vary the HX fan speed based on oil temperature as measured by the thermistor. The 48 VDC generated by the heat exchanger, power supply is also sent to the power interface board. The 48 VDC is monitored by the power interface board. A solid state relay is also used to provide feedback to the JEDI that the 48 VDC is present. The 48 VDC is also used in the fan speed control circuit on the power interface board for the heat exchanger. The JEDI also has a pair of signals that are used to turn the both oil pump and fans on or off.

Compatible Products

VCT

VCT

Discovery 750 HD

Discovery 750 HD

Lightspeed Ultra

Lightspeed Ultra

Lightspeed Plus

Lightspeed Plus

Lightspeed QXi

Lightspeed QXi

Discovery ST

Discovery ST

Discovery ST (64 Slice)

Discovery ST (64 Slice)

Discovery ST (128 Slice)

Discovery ST (128 Slice)

Substitute Parts :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
6750190

VCT Power IF PWA
