AMX-4 X EMC Base to Column Cable

2150956
X-Ray
GE HealthCare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Flexible Wire
  • Easy to Connect Crimp Terminal
  • Durable
  • Very good conductivity

Product Overview

This AMX-4 X-Ray EMC base to Column Cable assembly consists of 16 conductors of size 16 AWG and one of size 18 AWG, one size #10 and two size #1/4 ring terminals, and twenty six 1/4 inch quick connect crimp terminals. All these parts are assembled together to form a complete column cable. The cable's 18 AWG and 16 AWG heavy copper conductor gives good conductivity for reliable operation and efficient functioning. The cable can be connected using its tin plated brass quick connect terminals and tin plated copper ring terminals. The cable jacket is made of polybutylene terephthalate which provides good insulation, chemical resistance and high strength. This cable assembly can be used with AMX4 portable X-Ray machines.
